Single Lever Sink Mixer – Chrome

Product Code

FLP-CHR-5177BPM

Description

Single Lever Sink Mixer (Table Mounted) with Extractable Hand Shower Dual Flow Complete with 1.2m Long Tube with 450mm Long Braided Hoses

Connection Size

Braided hoses, 1/2″ FIP (WRAS Approved)

Withstand Pressure

10 Bar

Flow Rate

13.52 LPM @ 3 bar

Recommended Water Pressure

0.5 Bar – 5 Bar

Brass Specification in Percentage

• Brass Ingots as per IS:1264-1997: Cu (58.0-63.0), Sn (0.0-1.0), Pb (0.5-2.5), Ni (0.0-1.0), Al (0.2-0.8), Mn (0.0-0.5), Total Impurity (0.0-2.0), Zn (Remainder)
• Brass Rod as per IS:319-1989: Cu (56.0-59.0), Pb (2.0-3.5), Fe (0.0-0.35), Total Impurity (0.0-0.7), Zn (Remainder)
• Brass Pipe as per IS:407-1996: Cu (62.0-65.0), Pb (0.0-0.3), Fe (0.0-0.01), Total Impurity (0.0-0.6), Zn (Remainder)

Cartridge Specification

• Cartridge with Temperature Limiter
• Cartridge with Brass Spindle
• Life Cycle EN 817: 70,000 cycles (Standard) – 2.1 LAC Cycles as per EN 817* – 10.5 LAC Cycles (ON/OFF)*
• Water Tightness: 16 bar (Pass)
• Pressure Resistance: 25 bar (Pass)

Finish

Plating: Nickel-10.0 micron, Chromium-0.3 micron

Salt Spray: 500 hrs + Validated

Adhesion: Pass

Available Colour Finishing

Black Chrome (BCH) & Black Matt (BLM)

Disclaimer

Our every effort has been made to ensure factual accuracy; the information presented is subject to changes due to requirements in different sites, markets and/or countries. 10% variation in flow rate may be possible. Jaquar reserves the right to make the necessary amendments at any time without prior notice.
