Description
Product Code
OPP-CHR-15021PM
Description
Pillar Cock with 200mm Extension Body
Flow Rate: 16.79 LPM @ 3 bar
Recommended Water Pressure: 0.5 Bar – 5 Bar
Flow Regulator: By using flow regulators (Product should be ordered with suffix as G-2.5 LPM, GA-6.0 LPM, GB-8.0 LPM, GD-3.8 LPM & GE-1.3 LPM @ 3.0 Bar pressure) one can regulate the flow rate.
Material Composition
Brass Ingots as per IS:1264-1997
Cu: 58.0 – 63.0,
Sn: 0.0 – 1.0,
Pb: 0.5 – 2.5,
Ni: 0.0 – 1.0,
Al: 0.2 – 0.8,
Mn: 0.0 – 0.5,
Total Impurity: 0.0 – 2.0,
Zn: Remainder
Brass Rod as per IS:319-1989
Cu: 56.0 – 59.0,
Pb: 2.0 – 3.5,
Fe: 0.0 – 0.35,
Total Impurity: 0.0 – 0.7,
Zn: Remainder
Brass Sheets as per IS:410-1977
Cu: 61.5 – 64.5,
Pb: 0.0 – 0.3,
Fe: 0.0 – 0.075,
Total Impurity: 0.0 – 0.6,
Zn: Remainder
Cartridge Specification
Fittings: Components have WRAS Approved for food grade conformity with Brass Housing and Spindle
Life Cycle: EN 200: 200,000 cycles (Standard) – 5.0 LAC Cycles as per EN 200*
Water Tightness: 16 bar (Pass)
Pressure Resistance: 25 bar (Pass)
Finish
Plating: Nickel – 10.0 micron, Chromium – 0.3 micron
Salt Spray: 500 hrs + (Validated)
Adhesion: Pass
Aerator Size: WRAS, ACS Approved (M20X1)
Available Colour Finishing
Antique Bronze (ABR), Antique Copper (ACR), Black Chrome (BCH), Black Matt (BLM), Gold Dust (GDS), Auric Gold (GLD), Graphite (GRF), Stainless Steel Finish (SSF) & White Matt (WHM)
Disclaimer
Our every effort has been made to ensure factual accuracy; the information presented is subject to changes due to requirements in different sites, markets and/or countries. 10% variation in flow rate may be possible. Jaquar reserves the right to make the necessary amendments at any time without prior notice.
* As per in-house testing done on automatic life cycle testing machine made by Giussani, Italy
