Hand Shower (Health Faucet) – Chrome

Product Code

For Chrome / White Matt Finish: ALD-XXX-573 – Hand Shower (Health Faucet) with 8mm Dia, 1 Meter Long Flexible Tube & Wall Hook

For Color Finish: ALD-XXX-573M/PD – Hand Shower (Health Faucet) with 8mm Dia, 1 Meter Long Flexible Tube & Wall Hook

Flow Rate

11.65 LPM @ 3 bar

Flow Regulator

By using flow regulators (Product should be ordered with suffix as GA-6.0 LPM, GB-8.0 LPM & GD-3.8 LPM @ 3.0 Bar pressure) one can regulate the flow rate.

Recommended Water Pressure

1.0 Bar – 3.0 Bar

Material Composition Specification in Percentage

• Brass Rod as per IS:319-1989: Cu (56.0-59.0), Pb (2.0-3.5), Fe (0.0-0.35), Total Impurity (0.0-0.7), Zn (Remainder)
• Brass Sheets as per IS:410-1977: Cu (61.5-64.5), Pb (0.0-0.3), Fe (0.0-0.075), Total Impurity (0.0-0.6), Zn (Remainder)
• Brass Pipe as per IS:407-1996: Cu (62.0-65.0), Pb (0.0-0.3), Fe (0.0-0.01), Total Impurity (0.0-0.6), Zn (Remainder)
• ABS: Specific Gravity (g/cm²) (1.06-1.10), Melt Mass Flow Rate (g/10 min.) (20-26), Rockwell Hardness (95-115), DTUL @ 66 psi (0.45 MPa) (°C) (78-102)

Water Tightness & Pressure Resistance

Water Tightness: 4 bar (Pass)
Pressure Resistance: 5 bar (Pass)

Finish

Plating: Nickel-10.0 micron, Chromium-0.3 micron

Salt Spray: 500 hrs + Validated

Adhesion: Pass

Available Colour Finishing

For (ALD-573M/PD): Antique Bronze (ABR), Antique Copper (ACR), Black Chrome (BCH), Blush Gold Bright PVD (BGP), Gold Bright PVD (GBP), Gold Dust (GDS), Auric Gold (GLD), Gold Matt PVD (GMP), Graphite (GRF) & Stainless Steel (SSF)

Disclaimer

Our every effort has been made to ensure factual accuracy; the information presented is subject to changes due to requirements in different sites, markets and/or countries. 10% variation in flow rate may be possible. Jaquar reserves the right to make the necessary amendments at any time without prior notice.
