Bib Cock – Chrome

Product Code

VGP-CHR-81037

Description

Bib Cock with Wall Flange

Flow Rate

14.65 LPM @ 3 bar

Flow Regulator

By using flow regulators (Product should be ordered with suffix as G-2.5 LPM, GA-6.0 LPM, GB-8.0 LPM, GD-3.8 LPM & GE-1.3 LPM @ 3.0 Bar pressure) one can regulate the flow rate.

Recommended Water Pressure

0.5 Bar – 5 Bar

Brass Specification in Percentage

• Brass Ingots as per IS:1264-1997: Cu (58.0-63.0), Sn (0.0-1.0), Pb (0.5-2.5), Ni (0.0-1.0), Al (0.2-0.8), Mn (0.0-0.5), Total Impurity (0.0-2.0), Zn (Remainder)
• Brass Rod as per IS:319-1989: Cu (56.0-59.0), Pb (2.0-3.5), Fe (0.0-0.35), Total Impurity (0.0-0.7), Zn (Remainder)
• Brass Sheets as per IS:410-1977: Cu (61.5-64.5), Pb (0.0-0.3), Fe (0.0-0.075), Total Impurity (0.0-0.6), Zn (Remainder)

Cartridge Specification

• Fittings: Components have WRAS Approved for food grade conformity with Brass Housing and Spindle
• Life Cycle EN 200: 200,000 cycles (Standard) – 5.0 LAC Cycles as per EN 200*
• Water Tightness: 16 bar (Pass)
• Pressure Resistance: 25 bar (Pass)
• Aerator Size: WRAS, ACS Approved (20X1)

Finish

Plating: Nickel-10.0 micron, Chromium-0.3 micron

Salt Spray: 500 hrs + Validated

Adhesion: Pass

Available Colour Finishing

Antique Bronze (ABR), Antique Copper (ACR), Black Chrome (BCH), Black Matt (BLM), Gold Dust (GDS), Auric Gold (GLD), Graphite (GRF), Stainless Steel Finish (SSF) & White Matt (WHM)

Disclaimer

Our every effort has been made to ensure factual accuracy; the information presented is subject to changes due to requirements in different sites, markets and/or countries. 10% variation in flow rate may be possible. Jaquar reserves the right to make the necessary amendments at any time without prior notice.
